摘要:
在现有区块链版权存证系统中，各种环签名占用过多存储空间，数据共识算法效率有待提高。针对此问题，使用动态累加器对环成员公钥进行累加，分别设计初始化、系统选取、密钥生成、签名生成、签名验证等算法，构造多私钥生成器（PKG）的身份基简短可验证环签名方案；为主节点选取设置信用阈值，降低允许参与共识的最大节点数，改进已有的联盟链共识算法；利用所构环签名方案及改进的共识算法，提出一种新的区块链版权存证协议。对所构签名方案的不可伪造性及匿名性进行形式化证明；对所构签名方案的计算效率及存储空间进行分析和仿真，对存证系统的共识算法和容错性进行实验评估。结果显示：所提协议节省了签名时间开销和存储空间，提高了共识效率和容错性。
Abstract:In the existing blockchain copyright storage systems, various ring signatures occupied too much storage space, and the efficiency of the data consensus algorithm needed to be improved. The public keys of the ring members were accumulated using a dynamic accumulator in order to solve these issues. Various algorithms were then designed, including initialization, system selection, key generation, signature generation, and signature verification, to create an ID-based short verifiable ring signature scheme with multiple private key generators (PKG). The credit threshold was set for the primary node selection, the maximum number of nodes allowed to participate in the consensus was reduced, and the existing consortium blockchain consensus algorithm was improved. Using the new ring signature scheme constructed and the improved consensus algorithm, a new blockchain copyright storage protocol was proposed. Finally, the unforgeability and anonymity of the signature scheme were formally proved. The consensus algorithm and fault tolerance of the system were assessed experimentally, and the computational effectiveness and storage capacity of the signature scheme were examined and simulated. The results show that the proposed protocol saves the signature time and storage space, and improves the consensus efficiency and fault tolerance.
-
表 1 各签名方案性能对比
Table 1. Performance comparison of each signature schemes
方案 签名生成 签名验证 签名大小 文献[8] $(3n - 1){T_{\mathrm{M}}} + (4n - 3){T_{\mathrm{A}}} + (3n - 1){T_{\mathrm{H}}}$ $(2n + 2){T_{\mathrm{M}}} + (2n + 1){T_{\mathrm{A}}} + 2n{T_{\mathrm{H}}}$ $|{G_1}| + (n + 1)|{{\bf{Z}}_p}|$ 文献[12] $(n + 2t){T_{\mathrm{M}}} + (2n - 1){T_{\mathrm{A}}} + {T_{\mathrm{H}}}$ $n{T_{\mathrm{M}}} + 2n{T_{\mathrm{A}}} + 2{T_{\mathrm{B}}} + {T_{\mathrm{H}}}$ $n|U| + (n + 2)|{G_1}| + |{\bf{Z}}_p^*| + |{{\bf{Z}}_p}[x]|$ 文献[13] $(2n + 1){T_{\mathrm{M}}} + (2n + 1){T_{\mathrm{A}}} + (n + 1){T_{\mathrm{H}}}$ $n{T_{\mathrm{M}}} + (2n - 1){T_{\mathrm{A}}} + 2{T_{\mathrm{B}}} + {T_{\mathrm{D}}}$ $(n + 1)|{G_1}| + 2|{\mathrm{PKGP}}|$ 文献[14] $(2n + 1){T_{\mathrm{M}}} + 3(n - 1){T_{\mathrm{A}}} + (n + 1){T_{\mathrm{H}}}$ $n{T_{\mathrm{M}}} + (2n - 1){T_{\mathrm{A}}} + 3{T_{\mathrm{B}}} + {T_{\mathrm{H}}}$ $(n + 1)|{G_1}| + k|{\mathrm{PKGP}}|$ 本文方案 $18{T_{\mathrm{M}}} + 8{T_{\mathrm{A}}} + 2{T_{\mathrm{H}}}$ $9{T_{\mathrm{M}}} + 8{T_{\mathrm{A}}} + 4{T_{\mathrm{B}}}$ $9|{G_1}| + 5|{{\bf{Z}}_p}| + 2|{\mathrm{PKGP}}|$
下载: 导出CSV
-
[1] YANG D, LONG C N, XU H, et al. A review on scalability of blockchain[C]//Proceedings of the 2nd International Conference on Blockchain Technology. New York: ACM, 2020: 1-6. [2] TANG F, PANG J J, CHENG K F, et al. Multiauthority traceable ring signature scheme for smart grid based on blockchain [J/OL]. Wireless Communications and Mobile Computing. (2021-04-10)[2022-11-28]. http://doi.org/10.1155/2021/ 5566430. [3] RIVEST R L, SHAMIR A, TAUMAN Y. How to leak a secret [C]// Proceedings of the 7th International Conference on the Theory and Application of Cryptology and Information Security: Advances in Cryptology. Berlin: Springer, 2001: 552-565. [4] 蔡晓晴, 邓尧, 张亮, 等. 区块链原理及其核心技术[J]. 计算机学报, 2021, 44(1): 84-131.CAI X Q , DENG Y , ZHANG L , et al. The principle and core technology of blockchain [J]. Chinese Journal of Computers, 2021, 44(1): 84-131(in Chinese). [5] 任艳丽, 徐丹婷, 张新鹏, 等. 基于门限环签名的可删除区块链[J]. 通信学报, 2019, 40(4): 71-82.REN Y L, XU D T, ZHANG X P, et al. Deletable blockchain based on threshold ring signature[J]. Journal on Communications, 2019, 40(4): 71-82(in Chinese). [6] LV J Q, WANG X M. Verifiable ring signature[C]//Proceedings of the 9th International Conference on Distributed Multimedia Systems. New York: Mathematics and Computer Science, 2003: 32-44. [7] ZHANG F G, KIM K. ID-based blind signature and ring signature from pairings[C]//Proceedings of the Lecture Notes in Computer Science. Berlin: Springer, 2002: 533-547. [8] WANG W S, LI X, QIU X Q, et al. A privacy preserving framework for federated learning in smart healthcare systems[J]. Information Processing & Management, 2023, 60(1): 103167. [9] GENG H T, CUI X C. An anonymous buyer-seller watermarking protocol based on convertible ring signature[J]. Journal of Qufu Normal University, 2017, 43(2): 52-59. [10] LI F Q, LIU K M, WU H Y, et al. MaSRChain: A trusted manuscript submission and review system based on blockchain[C]//Proceedings of the Lecture Notes in Computer Science. Berlin: Springer, 2020: 18-26. [11] 林孟晨, 冯勇, 付晓东. 一种基于联盟区块链的电子医疗记录安全共享模型[J]. 小型微型计算机系统, 2021, 42(10): 2161-2166.LIN M C, FENG Y, FU X D. SMCB: A safe sharing model for electronic medical records based on consortium blockchain[J]. Journal of Chinese Computer Systems, 2021, 42(10): 2161-2166(in Chinese). [12] 周艺华, 吕竹青, 杨宇光, 等. 基于区块链技术的数据存证管理系统[J]. 信息网络安全, 2019(8): 8-14.ZHOU Y H, LYU Z Q, YANG Y G, et al. Data deposit management system based on blockchain technology[J]. Netinfo Security, 2019(8): 8-14(in Chinese). [13] 翟社平, 陈思吉, 汪一景. 基于区块链的数字版权存证系统模型研究[J]. 计算机工程与应用, 2020, 56(19): 13-21.ZHAI S P, CHEN S J, WANG Y J. Research on digital copyright storage system model based on blockchain[J]. Computer Engineering and Applications, 2020, 56(19): 13-21(in Chinese). [14] 陈思吉, 翟社平, 汪一景. 一种基于环签名的区块链隐私保护算法[J]. 西安电子科技大学学报, 2020, 47(5): 86-93.CHEN S J, ZHAI S P, WANG Y J. Blockchain privacy protection algorithm based on ring signature[J]. Journal of Xidian University, 2020, 47(5): 86-93(in Chinese). [15] 王玲玲, 张国印, 马春光. 适用于电子现金协议的简短关联环签名方案[J]. 北京邮电大学学报, 2008, 31(1): 102-106. doi: 10.3969/j.issn.1007-5321.2008.01.024WANG L L, ZHANG G Y, MA C G. A short linkable ring signature scheme for E-cash protocol[J]. Journal of Beijing University of Posts and Telecommunications, 2008, 31(1): 102-106(in Chinese). doi: 10.3969/j.issn.1007-5321.2008.01.024 [16] 王玲玲. 环签名及其应用的研究[D]. 哈尔滨: 哈尔滨工程大学, 2008: 31-43.WANG L L. Research on ring signature and its application[D]. Harbin: Harbin Engineering University, 2008: 31-43(in Chinese). [17] LUO X Y, XUE K P, XU J, et al. Blockchain based secure data aggregation and distributed power dispatching for microgrids[J]. IEEE Transactions on Smart Grid, 2021, 12(6): 5268-5279. doi: 10.1109/TSG.2021.3099347 [18] QU J. Blockchain in medical informatics[J]. Journal of Industrial Information Integration, 2022, 25: 100258. doi: 10.1016/j.jii.2021.100258 [19] ZHANG X D, LI R, ZHAO H. A parallel consensus mechanism using PBFT based on DAG-lattice structure in the Internet of vehicles[J]. IEEE Internet of Things Journal, 2023, 10(6): 5418-5433. doi: 10.1109/JIOT.2022.3222217 [20] 陈子豪, 李强, 甘俊, 等. VC Chain: 联盟式音视频版权区块链系统[J]. 计算机工程与科学, 2019, 41(11): 1939-1948.CHEN Z H, LI Q, GAN J, et al. VC Chain: An alliance audio-video copyright blockchain system[J]. Computer Engineering & Science, 2019, 41(11): 1939-1948(in Chinese). [21] 孙嘉豪, 孟翔斯, 张浩运, 等. 基于改进 PBFT 的区块链知识产权保护模型[J]. 计算机工程, 2020, 46(12): 134-141.SUN J H, MENG X S, ZHANG H Y, et al. Intellectual property protection model using blockchain based on improved PBFT[J]. Computer Engineering, 2020, 46(12): 134-141(in Chinese). [22] KUDVA S, BADSHA S, SENGUPTA S, et al. Towards secure and practical consensus for blockchain based VANET[J]. Information Sciences, 2021, 545: 170-187. doi: 10.1016/j.ins.2020.07.060 [23] FENG M Y, ZHENG J L, HE S Y, et al. CRBFT: An optimized blockchain algorithm for edge-based IoT system[J]. IEEE Sensors Journal, 2022, 22(23): 23200-23208. doi: 10.1109/JSEN.2022.3215152 [24] NGUYEN L. Accumulators from bilinear pairings and applications[C]//Proceedings of the Lecture Notes in Computer Science. Berlin: Springer, 2005: 275-292. [25] POINTCHEVAL D, STERN J. Security arguments for digital signatures and blind signatures[J]. Journal of Cryptology, 2000, 13(3): 361-396. doi: 10.1007/s001450010003 [26] 杨波. 现代密码学[M]. 4版. 北京: 清华大学出版社, 2017: 273-274.YANG B. Cyberspace security[M]. 4th ed. Beijing: Tsinghua University Press, 2017: 273-274(in Chinese). -
