基于U-Net的掌纹图像增强与ROI提取

陆展鸿; 单鲁斌; 苏立循; 焦雨欣; 王家骅; 王海霞

doi:10.13700/j.bh.1001-5965.2020.0309

基于U-Net的掌纹图像增强与ROI提取

doi: 10.13700/j.bh.1001-5965.2020.0309

1.
杭州海康威视数字技术股份有限公司, 杭州 310051
2.
浙江工业大学信息工程学院, 杭州 310023
3.
浙江工业大学计算机科学与技术学院, 杭州 310023

基金项目:

浙江省重点研发计划 2019C01007

详细信息

作者简介:
陆展鸿男, 学士。主要研究方向:图像识别技术

王海霞女, 博士, 副教授, 博士生导师。主要研究方向:精密测量与图像处理

通讯作者:
王海霞, E-mail:hxwang@zjut.edu.cn

中图分类号: TP391.41
计量
- 文章访问数: 1574
- HTML全文浏览量: 367
- PDF下载量: 222
- 被引次数: 0
出版历程
- 收稿日期: 2020-07-01
- 录用日期: 2020-07-22
- 网络出版日期: 2020-09-20

Palmprint enhancement and ROI extraction based on U-Net

1.
Hangzhou Hikvision Digital Technology Co., Ltd., Hangzhou 310051, China
2.
College of Information Engineering, Zhejiang University of Technology, Hangzhou 310023, China
3.
College of Computer Science and Technology, Zhejiang University of Technology, Hangzhou 310023, China

Funds:

Zhejiang Povincial Key Research and Development Program of China 2019C01007

More Information

Corresponding author: WANG Haixia, E-mail:hxwang@zjut.edu.cn

摘要

摘要:
掌纹因稳定性、唯一性、难复制性及易获取等特点，是极具应用潜力的生物识别特征。针对掌纹识别中，获取掌纹感兴趣区域（ROI）与增强掌纹信息普遍存在的时间成本大，方法之间有依赖关系等问题，提出了一种基于U-Net神经网络结构的掌纹图像预处理方法。通过香港理工大学掌纹库进行实验对比，结果表明，所提方法能消除预处理方法之间的相互影响，实现对掌纹图像的去噪与增强处理，并能快速、高精度提取感兴趣区域。
- U-Net /
- 感兴趣区域(ROI)增强 /
- 深度学习 /
- 感兴趣区域(ROI)提取 /
- 掌纹
Abstract:
Palmprint is a biometric feature with great application potential due to its stability, uniqueness, hardness in copying, and easy access.In the palmprint recognition, palmprint Region of Interest(ROI) acquisition and palmprint enhancement usually have the problems of high time cost and high dependency between methods.This paper proposes a palmprint preprocessing method based on U-Net neural network structure.The experiments are carried out on palmprint database from Hong Kong Polytechnic University.The results show that the proposed method can eliminate the mutual influence between the preprocessing methods.Both denoising and enhancement of palmprint images are realized, and the region of interest can be extracted quickly and accurately; plamprint
- U-Net /
- Region of Interest (ROI) enhancement /
- deep learning /
- Region of Interest (ROI) extraction /
- plamprint

HTML全文

图 1 本文方法流程图

Figure 1. Proposed method flow chart

下载: 全尺寸图片幻灯片

图 2 预处理步骤

Figure 2. Pre-processingsteps

下载: 全尺寸图片幻灯片

图 3 U-Net神经网络结构

Figure 3. U-Net neural network structure

下载: 全尺寸图片幻灯片

图 4 激活函数图形

Figure 4. Graph of activation functions

下载: 全尺寸图片幻灯片

图 5 关键点及掌纹对应谷点

Figure 5. Key points and correspondingly valley points on plamprint

下载: 全尺寸图片幻灯片

图 6 ROI提取处理

Figure 6. ROI extraction processing diagram

下载: 全尺寸图片幻灯片

图 7 不同掌纹图像的增强结果

Figure 7. Enhancement results of different palmprint images

下载: 全尺寸图片幻灯片

图 8 BM3D去噪+Gabor小波增强后为真值的掌纹增强对比

Figure 8. Comparison of palmprint enhancement after BM3D denoising +Gabor wavelet enhancement as truth value

下载: 全尺寸图片幻灯片

图 9 OBLNM增强后为真值的掌纹增强对比

Figure 9. Comparison of palmprint enhancement after OBLNM enhancement as truth value

下载: 全尺寸图片幻灯片

表 1 U-Net神经网络模型参数

Table 1. U-Net neural network model parameters

层类型	输入大小	滤波器大小	重复次数
卷积模块	1×384×280	3×3	1
卷积模块	64×384×280	3×3	1
池化层	64×384×280	2×2	1
卷积模块	64×192×140	3×3	2
池化层	128×192×140	2×2	1
卷积模块	128×96×70	3×3	2
池化层	256×96×70	2×2	1
卷积模块	256×48×35	3×3	2
上采样层	512×48×35	3×3	1
卷积模块	512×96×70	3×3	2
上采样层	256×96×70	3×3	1
卷积模块	256×192×140	3×3	2
上采样层	128×192×140	3×3	1
卷积模块	128×384×280	3×3	1
卷积模块	64×384×280	3×3	1
卷积模块	64×384×280	1×1	1

下载: 导出CSV

表 2 掌纹增强效果比较结果

Table 2. Comparison results of palmprint enhancement

方法	BM3D去噪+Gabor小波增强后为真值			OBLNM增强后为真值
方法	PSNR	Entropy	AMBE	PSNR	Entropy	AMBE
BM3D去噪+Gabor小波增强	24.727 6	6.435 6	3.163 0	24.049 3	6.531 6	4.168 1
OBLNM	23.171 6	6.916 0	12.419 8	26.334 8	6.877 0	5.930 9
RKTFILT	23.499 4	6.820 0	15.239 3	28.022 2	6.753 7	6.806 8
SRAD	26.925 8	6.005 4	7.346 4	27.037 8	6.154 6	5.653 2
本文方法	27.120 8	7.247 6	3.165 3	27.916 9	6.920 7	3.210 1

下载: 导出CSV

表 3 掌纹感兴趣区域重合度分析

Table 3. Analysis of coincidence degree of palmprint ROI

方法	面积重合率/%
方法1	91.18
方法2	88.00
本文方法	94.00

下载: 导出CSV

表 4 掌纹分割图像相似度对比

Table 4. Similarity comparison of palmprint segmentation images

方法	Cosin相似度/%	哈希相似度/%
方法1	99.32	73.17
方法2	99.13	71.61
本文方法	99.49	76.47

下载: 导出CSV

表 5 每张掌纹图像处理时间

Table 5. Processing time of each palmprint image

方法	时间/ms
方法	增强	分割	增强和分割
方法1	1 355.73	32.23	1 387.96
方法2	1 355.73	14.49	1 370.22
本文方法			90.49

下载: 导出CSV
