基于谐波系数幅值平均的复合调制引信抗扫频式干扰方法

陈齐乐; 郝新红; 闫晓鹏; 乔彩霞; 王雄武

doi:10.13700/j.bh.1001-5965.2019.0451

基于谐波系数幅值平均的复合调制引信抗扫频式干扰方法

doi: 10.13700/j.bh.1001-5965.2019.0451

北京理工大学机电学院, 北京 100089

基金项目:

国家自然科学基金 61871414

国家“973”计划 613196

详细信息

作者简介:
陈齐乐  男, 博士研究生。主要研究方向:无线电引信信号处理技术

郝新红  女, 博士, 副教授, 博士生导师。主要研究方向:中近程探测及控制技术、引信抗干扰技术

闫晓鹏  男, 博士, 副教授, 博士生导师。主要研究方向:电子对抗技术、引信干扰技术

乔彩霞  女, 硕士研究生。主要研究方向:无线电引信目标特征识别技术

王雄武  男, 硕士研究生。主要研究方向:无线电引信抗干扰技术

通讯作者:
郝新红, E-mail: haoxinhong@bit.edu.cn

中图分类号: TJ43⁺4.1
计量
- 文章访问数: 1063
- HTML全文浏览量: 186
- PDF下载量: 272
- 被引次数: 0
出版历程
- 收稿日期: 2019-08-20
- 录用日期: 2019-09-27
- 网络出版日期: 2020-07-20

Anti sweep jamming method of hybrid modulation fuze based on harmonic coefficient amplitude averaging

School of Mechatronical Engineering, Beijing Institute of Technology, Beijing 100089, China

Funds:

National Natural Science Foundation of China 61871414

National Basic Research Program of China 613196

More Information

Corresponding author: HAO Xinhong. E-mail:haoxinhong@bit.edu.cn

摘要

摘要:
为提高混沌码调相与线性调频（CCPM-LFM）复合调制无线电引信的抗扫频式干扰性能，分析了扫频式干扰作用下复合调制无线电引信的响应，并提出了谐波系数幅值平均的抗干扰方法。在瞬时相关和谐波解调串联（ICHD）定距算法原理的基础上，采用快速傅里叶变换（FFT）算法提取谐波包络，并对多次FFT所得谐波系数幅值平均，充分利用混沌码的随机性和统计特性抑制干扰。理论和仿真结果表明：所提方法在不影响引信定距精度的前提下，能够有效抑制扫频干扰。
- 无线电引信 /
- 抗干扰方法 /
- 复合调制 /
- 谐波系数 /
- 统计特性
Abstract:
To improve the anti sweep jamming performance of the Chaotic Codes Phase Modulation and Linear Frequency Modulation (CCPM-LFM) hybrid modulation radio fuze, the response of the CCPM-LFM fuze under sweep jamming was analysed, and an anti jamming method based on harmonic coefficient amplitude average was proposed. This method was based on the ranging principle of Instantaneous Correlation Harmonic Demodulation (ICHD), and the harmonic envelope extraction was realized by Fast Fourier Transform (FFT) algorithm. By averaging the harmonic coefficient amplitudes obtained from multiple times of FFT, this method took the advantage of the random and statistical characteristics of the chaotic codes, and the jamming was effectively suppressed. Theoretical and simulation results show that the method can effectively suppress the sweep jamming without affecting the ranging resolution of the fuze.
- radio fuze /
- anti jamming method /
- hybrid modulation /
- harmonic coefficient /
- statistical characteristics

HTML全文

图 1 复合调制引信原理框图

Figure 1. Functional block diagram of hybrid modulation fuze

下载: 全尺寸图片幻灯片

图 2 扫频式干扰效果示意图

Figure 2. Schematic of sweep jamming effectiveness

下载: 全尺寸图片幻灯片

图 3 基于谐波系数幅值平均的抗干扰方法原理

Figure 3. Schematic diagram of anti jamming method based on harmonic coefficient amplitude averaging

下载: 全尺寸图片幻灯片

图 4 定距算法仿真结果

Figure 4. Simulation results of ranging algorithms

下载: 全尺寸图片幻灯片

图 5 距离旁瓣抑制

Figure 5. Ranging sidelobe suppression

下载: 全尺寸图片幻灯片

图 6 扫频式干扰抑制

Figure 6. Sweep jamming suppression

下载: 全尺寸图片幻灯片

图 7 不同G值引信能够正常工作的最大SJR

Figure 7. Maximum SJR of fuse in normal work situation with different values of G

下载: 全尺寸图片幻灯片

图 8 G值对算法性能的影响

Figure 8. Effect of values of G on algorithm performance

下载: 全尺寸图片幻灯片

表 1 仿真参数

Table 1. Simulation parameters

参数	数值
载波频率f₀/MHz	300
调制频率f_m/kHz	25
调频带宽ΔF/MHz	50
码元宽度T_c/ns	50
引信同目标的初始距离R/m	15~0
弹目径向相对运动速度v₀/(m·s^-1)	500
输入信干比SJR/dB	-10
扫频起始/终止频率f_j0~f_jw/MHz	350~450
扫频点数N	100
扫频驻留时间T_dw/ms	1

下载: 导出CSV

参考文献(16)

[1]	郭晨曦, 郝新红, 栗苹, 等.毫米波调频引信的优化二维FFT信号处理算法[J].北京麻豆精品秘国产传媒学报, 2020, 46(1):220-228. doi: 10.13700/j.bh.1001-5965.2019.0185 GUO C X, HAO X H, LI P, et al.Optimized two-dimensional FFT signal processing algorithm for millimeter-wave FM fuze[J].Jornal of Beijing University of Aeronautics and Astronautics, 2020, 46(1):220-228(in Chinese). doi: 10.13700/j.bh.1001-5965.2019.0185
[2]	郝新红, 杜涵宇, 陈齐乐.调频引信粗糙面目标与干扰信号识别[J].北京麻豆精品秘国产传媒学报, 2019, 45(10):1946-1955. doi: 10.13700/j.bh.1001-5965.2019.0036 HAO X H, DU H Y, CHEN Q L.Rough surface target and jamming signal recognition of FM fuze[J].Jornal of Beijing University of Aeronautics and Astronautics, 2019, 45(10):1946-1955(in Chinese). doi: 10.13700/j.bh.1001-5965.2019.0036
[3]	刘少坤, 闫晓鹏, 栗苹, 等.脉冲多普勒引信康周期调制干扰性能研究[J].北京麻豆精品秘国产传媒学报, 2018, 44(5):1018-1026. doi: 10.13700/j.bh.1001-5965.2017.0369 LIU S K, YAN X P, LI P, et al.Anti periodic modulation jamming performance of pulse Doppler fuze[J].Journal of Beijing University of Aeronautice and Astronautics, 2018, 44(5):1018-1026(in Chinese). doi: 10.13700/j.bh.1001-5965.2017.0369
[4]	崔占忠, 宋世和, 徐立新.近炸引信原理[M].3版.北京:北京理工大学出版社, 2009:76-79. CUI Z Z, SONG S H, XU L X.Principle of proximity fuze[M].3rd ed.Beijing:Beijing Institute of Technology Press, 2009:76-79(in Chinese).
[5]	KONG Z J, LI P, YAN X P, et al.Anti-sweep jamming design and implementation using multi-channel harmonic timing sequence detection for short-range FMCW proximity sensors[J].Sensors, 2017, 17(9):2042.
[6]	孔志杰, 郝新红, 栗苹, 等.调频引信谐波时序检测抗干扰方法及实现[J].北京麻豆精品秘国产传媒学报, 2018, 44(3):549-555. doi: 10.13700/j.bh.1001-5965.2017.0224 KONG Z J, HAO X H, LI P, et al.Harmonic timing sequence detection anti-jamming method and its implementation for FM fuze[J].Journal of Beijing University of Aeronautics and Astronautics, 2018, 44(3):549-555(in Chinese). doi: 10.13700/j.bh.1001-5965.2017.0224
[7]	LI Z Q, HAO X H, CHEN H L, et al.Target signal recognition for CW Doppler proximity radio detector based on SVM[C]//2013 International Conference on Mechatronic Sciences, Electric Engineering and Computer(MEC).Piscataway: IEEE Press, 2013: 1160-1163.
[8]	黄莹, 郝新红, 孔志杰, 等.基于熵特征的调频引信目标与干扰信号识别[J].兵工学报, 2017, 38(2):255-262. HUANG Y, HAO X H, KONG Z J, et al.Recognition of target and jamming signal of FM fuze based on entropy[J].Acta Armamentarii, 2017, 38(2):255-262(in Chinese).
[9]	代健, 晏祺, 闫晓鹏, 等.基于模糊c-均值增量更新的脉冲多普勒引信干扰与目标信号识别[J].兵工学报, 2018, 39(9):1711-1720. DAI J, YAN Q, YAN X P, et al.Recognition of jamming and target signal for pulse Doppler fuze based on FCM algorithm with incremental update[J].Acta Armamentarii, 2018, 39(9):1711-1720(in Chinese).
[10]	孔志杰, 郝新红, 栗苹, 等.基于时序及相关检测的调频引信抗扫频干扰方法[J].兵工学报, 2017, 38(8):1483-1490. KONG Z J, HAO X H, LI P, et al.Method of anti-interference based on time series and correlation detection[J].Acta Armamentarii, 2017, 38(8):1483-1490(in Chinese).
[11]	高祥, 王利, 王露露, 等.基于混沌理论跳频引信技术的研究[J].现代防御技术, 2014, 42(3):43-48. GAO X, WANG L, WANG L L, et al.Frequency hopping fuze technology based on chaos theory[J].Modern Defence Technology, 2014, 42(3):43-48(in Chinese).
[12]	陈博, 郭东敏, 周涛.频率捷变引信多频点信息分路-融合信号处理方法[J].探测与控制学报, 2008, 30(3):59-64. CHEN B, GUO D M, ZHOU T.The method of signal processing for frequency agile fuze based on separate direction-fusion of many frequencies information[J].Journal of Detection & Control, 2008, 30(3):59-64(in Chinese).
[13]	韩东波, 洪飞.与弹头共型的超宽带微带引信天线[J].探测与控制学报, 2019, 42(2):40-43. HAN D B, HONG F.The UWB microstrip fuze antenna with the warhead tpye[J].Journal of Detection & Control, 2019, 42(2):40-43(in Chinese).
[14]	刘静, 赵惠昌, 周新刚, 等.伪码与线性调频复合调制信号分析[J].兵工学报, 2011, 32(10):1217-1222. LIU J, ZHAO H C, ZHOU X G, et al.Analysis of pseudo code and LFM compound modulation signal[J].Acta Armamentarii, 2011, 32(10):1217-1222(in Chinese).
[15]	陈齐乐, 晏祺, 郝新红, 等.无线电近炸引信混沌码调相与线性调频复合调制波形设计与分析[J].兵工学报, 2018, 39(11):2127-2137. CHEN Q L, YAN Q, HAO X H, et al.Analysis of transmitting waveform of radio fuze modulated by chaotic bi-phased code and hybrid linear frequency modulation[J].Acta Armamentarii, 2018, 39(11):2127-2137(in Chinese).
[16]	GU H, LIU G S, ZHU X H, et al.A new kind of noise radar-random binary phase coded CW radar[C]//Proceedings of the 1997 IEEE National Radar Conference.Piscataway: IEEE Press, 2002: 6202-6207.
