基于流动显示的翼尖涡不稳定频率测量

薛栋; 潘翀; 李广超

doi:10.13700/j.bh.1001-5965.2015.0594

基于流动显示的翼尖涡不稳定频率测量

doi: 10.13700/j.bh.1001-5965.2015.0594

北京麻豆精品秘国产传媒航空科学与工程学院流体力学教育部重点实验室, 北京 100083

基金项目:

航空科学基金(2013ZC51030)

详细信息

作者简介:
薛栋男,硕士研究生。主要研究方向:实验流体力学。 Tel.: 010-82318069 E-mail: xuedong1202@cq5520.com;潘翀男,博士,副教授。主要研究方向:湍流、转捩,流动不稳定性。 Tel.: 010-82318069 E-mail: panchong@cq5520.com;李广超男,博士,讲师。主要研究方向:流动控制,飞机防、除冰。 Tel.: 010-82318069 E-mail: liguangchao@cq5520.com

通讯作者:
李广超, Tel.: 010-82318069 E-mail: liguangchao@cq5520.com

中图分类号: O357;V211.7
计量
- 文章访问数: 871
- HTML全文浏览量: 133
- PDF下载量: 566
- 被引次数: 0
出版历程
- 收稿日期: 2015-09-10
- 修回日期: 2015-10-30
- 网络出版日期: 2016-04-20

Frequency measurement of wing-tip vortex instability by flow visualization

Fluid Mechanics Key Laboratory of Education Ministry, School of Aeronautic Science and Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

Funds:

Aeronautical Science Foundation of China (2013ZC51030)

摘要

摘要: 翼尖涡涡核振荡频率的准确测量是翼尖涡控制技术得以有效实施的重要前提。采用流动显示方法,研究了椭圆机翼翼尖涡在低雷诺数条件下的不稳定特性。分别采用单点谱分析和动力学模态分解技术,从流动显示图像序列中提取了涡核振荡的短波不稳定模态的频率,2种方法得到的频率相对误差最大不超过5%。研究结果表明:涡对的空间运动通常展现出长波与短波模态的耦合,涡核的高频短波振荡耦合在低频长波摆动中,以前者为主要含能模态;短波不稳定性的无量纲振荡频率随雷诺数的增大而增大、随机翼攻角的增大而减小。
- 翼尖涡 /
- 流动显示 /
- 短波不稳定性 /
- 频率 /
- 动力学模态分解
Abstract: The accurate measurement of the dominant frequency of wing-tip vortex core oscillation is essential for controlling the wing-tip vortex. In the present study, the instability of wing-tip vortex, which is generated from an elliptical wing, was investigated under low Reynolds number via flow visualization technique. Point-wise spectrum method and dynamic mode decomposition were applied to extract the dominant frequency of the short-wave instability of the wing-tip vortex core from the flow visualization image sequence, and the maximum relative error of these two methods is less than 5%. The results show that short-and long-wave instability modes are developed simultaneously among the vortex pair; the high-frequency vortex core oscillation is coupled with the slow side-to-side movement of vortex tube, and the former is the main energy mode; the non-dimensional frequency of the short-wave instability increases with the increase of Reynolds number, and decreases with the angle of attack increasing.
- wing-tip vortex /
- flow visualization /
- short-wave instability /
- frequency /
- dynamic mode decomposition
