多舱段载人航天器氧分压控制仿真分析

靳健; 徐进; 侯永青

doi:10.13700/j.bh.1001-5965.2014.0565

多舱段载人航天器氧分压控制仿真分析

doi: 10.13700/j.bh.1001-5965.2014.0565

中国空间技术研究院载人航天总体部, 北京 100094

基金项目:

国家重大工程技术专项

详细信息

通讯作者:
靳健(1980-),男,北京人,高级工程师,jinjian0331@126.com,主要研究方向为载人航天器热管理系统和载人环境控制系统设计.

中图分类号: V476
计量
- 文章访问数: 979
- HTML全文浏览量: 106
- PDF下载量: 428
- 被引次数: 0
出版历程
- 收稿日期: 2014-09-15
- 网络出版日期: 2015-08-20

Simulation analysis on oxygen partial pressure control of multi-cabin manned spacecraft

Institute of Manned Space System Engineering, China Academy of Space Technology, Beijing 100094, China

摘要

摘要: 为确保乘员安全性,载人航天器需通过氧分压控制系统将密封舱内的氧分压控制在指标范围内.提出了一种两舱段载人航天器密封舱氧分压控制系统数学模型,包括密封舱体、乘员、供氧组件、舱间通风(IMV)等多个子模块.通过与相关试验数据进行对比,证明了数学模型的准确性.针对由两个容积为60 m³密封舱组成的组合体,利用该模型分析了乘员驻留位置、舱间通风量、氧分压监测模式对两舱氧分压的影响.结果表明:当舱间通风量为0.5 m³/min 且6人驻留在氧分压非主控舱时,两舱氧分压上限差别达到2.2 kPa.两舱氧分压差别会随着舱间通风量的增加而减小.单舱监测模式和两舱监测模式对两舱氧分压影响并不显著,当舱间通风量超过1.5 m³/min时,两种控制模式的氧分压控制效果趋于一致.
- 载人航天器 /
- 密封舱 /
- 氧分压 /
- 舱间通风(IMV) /
- 监测模式
Abstract: In order to ensure crew security, oxygen partial pressure of pressurized cabin should be controlled within index range using oxygen partial pressure control system. A mathematical model about oxygen partial pressure control system of multi-cabin manned spacecraft was proposed, including pressurized cabin, crew, oxygen makeup assemble, inter module ventilation (IMV) and other sub-modules. Through comparing with experiment results, veracity of the model was proved. Using this model, influence of different factors to oxygen partial pressure of manned spacecraft with two pressurized cabins all with the volume of 60 m³ was analyzed, including crew location, inter module ventilation and oxygen partial pressure monitoring mode. According to results, oxygen partial pressure peak value difference between two cabins could reach 2.2 kPa when crew of 6 stay in un-control cabin and IMV flux is 0.5 m³/min. Oxygen partial pressure difference between two cabins keep reducing as the inter module ventilation flux increasing. Monitoring mode has little effect to oxygen partial pressure of two cabins. When IMV flux is beyond 1.5 m³/min, the difference between one-cabin monitoring mode and two-cabin monitoring mode could be ignored.
- manned spacecraft /
- pressurized cabin /
- oxygen partial pressure /
- inter module ventilation (IMV) /
- monitoring mode

HTML全文

参考文献(13)

[1]	Larson W J, Pranke L K.Human spaceflight:Mission analysis and design[M].New York:The McGraw-Hill Companies,2001:539-574.
[2]	林贵平,王普秀. 载人航天生命保障技术[M].北京:北京麻豆精品秘国产传媒出版社,2006:84-148. Lin G P,Wang P X.Life support technology of manned spacecraft[M].Beijing:Beihang University Press,2006:84-148(in Chinese).
[3]	戚发轫. 载人航天器技术[M].北京:国防工业出版社,1999:82-95. Qi F R.Manned spacecraft technology[M].Beijing:National Defense Industry Press,1999:82-95(in Chinese).
[4]	范剑峰,黄祖蔚. 载人飞船工程概论[M].北京:国防工业出版社,2000:52-70. Fan J F,Huang Z W.Introduction of manned spaceship industry[M].Beijing:National Defense Industry Press,,2000:52-70(in Chinese).
[5]	Antonacci M, Bruno G,Gera G,et al.The design and the verification of the ATV cargo carrier environmental control and life support system and water & gas delivery system,SAE 2000-01-2299[R].Warrendale,PA:SAE International,2000.
[6]	Anderson G, Martin C E.Evaluation and application of Apollo ECLS/ATCS systems to future manned missions,AIAA-2005-0703[R].Reston:AIAA,2005.
[7]	Mitchell K L, Bagdigian R M,Carrasquillo R L.Technical assessment of MIR-1 life support hardware for the international space station,NASA TM1994-108441[R].Washington,D.C.:NASA,1994.
[8]	Wieland P O. Living together in space:The design and operation of the life support systems on the international space station,NASA/TM1998-206956[R].Washington,D.C.:NASA,1998.
[9]	付仕明,裴一飞, 郄殿福.国际空间站集成ECLSS/TCS试验综述[J].航天器环境工程,2010,27(4):447-451. Fu S M,Pei Y F,Qie D F.Review of integrated ECLSS/TCS tests for ISS[J].Spacecraft Environment Engineering,2010,27(4):447-451(in Chinese).
[10]	徐向华,任建勋, 梁新刚,等.载人航天器密封舱内空气压力的动态分析[J].清华大学学报:自然科学版,2002,42(11):1492-1495. Xu X H,Ren J X,Liang X G,et al.Dynamic analysis of the cabin atmosphere in a manned spacecraft[J].Journal of Tsinghua University:Science and Technology,2002,42(11):1492-1495(in Chinese).
[11]	芮嘉白,郑传先, 王普秀.载人航天器密封舱压控制规律解析解极其实验验证[J].航天医学与医学工程,2001,14(4):264-267. Rui J B,Zheng C X,Wang P X.Analysis solution and experimental verification of pressure control function of the sealed module of manned space vehicle[J].Space Medicine & Medical Engineering,2001,14(4):264-267(in Chinese).
[12]	靳健,侯永青, 杨雷.载人航天器大气环境控制系统性能集成分析[J].航天器环境工程,2013,30(4):380-387. Jin J,Hou Y Q,Yang L.Integrated analysis of characteristics of the air environment control system of manned spacecraft[J].Space Environment Engineering,2013,30(4):380-387(in Chinese).
[13]	European Space Agency.Ecosimpro ECLSS library reference manual[M].Lawrenceville,GA:EA International,2008:316-319.
