基于模板匹配整帧屏幕视频帧内无损编码方法

冯立新; 陶品; 温江涛; 杨士强

doi:10.13700/j.bh.1001-5965.2014.0529

基于模板匹配整帧屏幕视频帧内无损编码方法

doi: 10.13700/j.bh.1001-5965.2014.0529

清华大学信息科学与技术国家实验室(筹), 北京 100084

基金项目:

国家核高基重大专项(2013ZX01039001-002-003)

详细信息

作者简介:
冯立新(1978—),男,山东临朐人,硕士研究生,fenglixin@gmail.com

通讯作者:
陶品(1974—),男,安徽芜湖人,副教授,taopin@tsinghua.edu.cn,主要研究方向为视频编码、嵌入式媒体处理.

中图分类号: TP37
计量
- 文章访问数: 1124
- HTML全文浏览量: 120
- PDF下载量: 533
- 被引次数: 0
出版历程
- 收稿日期: 2014-04-28
- 修回日期: 2014-10-25
- 网络出版日期: 2015-07-20

Lossless intra coding on whole frame for screen content video based on template matching

National Laborotary for Information Science and Technology, TNList, Tsinghua University, Beijing 100084, China

摘要

摘要: 当前主流的视频压缩标准,如H.264、HEVC等,主要是针对摄像机拍摄的视频而设计的.而屏幕内容(SC)的视频是由计算机生成的,无噪声,要求更高的压缩效率,同时与摄像机拍摄的视频相比包含更多的结构相似性.提出了一种利用屏幕视频中相似性的模板匹配帧内编码方法,采用由21个像素点组成的模板,以像素点为最小单位对整帧进行模板匹配,并使用哈希函数实现高效的模板查找,最后对残差图像进行熵编码.实验结果显示,与标准的HEVC扩展方法相比,该方法在无损编码上压缩率可以提高一倍,编码时间减小了近一半.
- 屏幕视频编码 /
- 模板匹配(TMM) /
- 高效率视频编码 (HEVC) /
- 残差图像 /
- 熵编码
Abstract: The-state-of-art video compression standards, such as H.264 and high efficiency video coding (HEVC) are mainly designed towards the camera-captured video. However, screen content (SC) video is created by the computer without noise, which needs higher efficiency than the camera-captured video. SC picture contains more structural similarity in contrast to camera-captured picture which could be used to improve the intra-picture compression ratio. A template matching method (TMM) was proposed by exploiting this similarity for SC intra lossless picture. The 21 pixel points template and the high efficiency 24-bits hash table were designed in TMM intra frame coding. For every picture, the first step was to use template matching for every pixel, and then speed up the matching processing by hash function, finally encode the residual picture by entropy coding. Experimental results show that TMM can double the lossless compression ratio compared to HEVC range extensions version 4.1 and reduce the compression time by half.
- screen content coding /
- template matching method (TMM) /
- high efficiency video coding (HEVC) /
- residual picture /
- entropy coding

HTML全文

参考文献(15)

[1]	Vermeir T.Use cases and requirements for lossless and screen content coding[C]//Proceedings of 13th Meeting of Joint Collaborative Team on Video Coding (JCT-VC) of ITU-T SG 16 WP 3 and ISO/IEC JTC 1/SC 29/WG 11, 2013: JCTVC-M0172.
[2]	Woo-Jin H, Sullivan G J, Ohm J, et al.Overview of the high efficiency video coding (HEVC) standard[J].IEEE Transactions on Circuits and Systems for Video Technology, 2012, 22(12): 1649-1668.
[3]	Zhou M H, Gao W, Jiang M Q, et al.HEVC lossless coding and improvements[J].IEEE Transactions on Circuits and Systems for Video Technology, 2012, 22(12): 1839-1843.
[4]	Saxena A, Chen H M, Felix F C.Rce3: Nearest-neighbor intra prediction for screen content video coding[C]//Proceedings of 15th Meeting of Joint Collaborative Team on Video Coding (JCT-VC) of ITU-T SG 16 WP 3 and ISO/IEC JTC 1/SC 29/WG 11, 2013: JCTVC-O0049.
[5]	Lan C L, Shi G M, Wu F.Compress compound images in H.264/MPGE-4 AVC by exploiting spatial correlation[J].IEEE Transactions on Image Processing, 2010, 19(4): 946-957.
[6]	Peng X, Xu J, Wu F.Exploiting inter-frame correlations in compound video coding[C]//Proceedings of IEEE Visual Communications and Image Processing (VCIP).Piscataway, NJ: IEEE Press, 2011: 6115952.
[7]	Guo X, Li B, Xu J Z, et al.AHG8: Major-color-based screen content coding[C]//Proceedings of 15th Meeting of Joint Collaborative Team on Video Coding (JCT-VC) of ITU-T SG 16 WP 3 and ISO/IEC JTC 1/SC 29/WG 11, 2013: JCTVC-O0182.
[8]	Lin T, Zhang P J, Wang S H, et al.Mixed chroma sampling-rate high efficiency video coding for full-chroma screen content[J].IEEE Transactions on Circuits and Systems for Video Technology, 2013, 23(1): 173-185.
[9]	Pang C, Sole J, Guo L W, et al.Nonrce3: Intra motion compensation with 2-D MVS[C]//Proceedings of 14th Meeting of Joint Collaborative Team on Video Coding (JCT-VC) of ITU-T SG 16 WP 3 and ISO/IEC JTC 1/SC 29/WG 11, 2013: JCTVC-N0256.
[10]	Budagavi M, Kwon D-K.AHG8: Video coding using intra motion compensation[C]//Proceedings of 13th Meeting of Joint Collaborative Team on Video Coding (JCT-VC) of ITU-T SG 16 WP 3 and ISO/IEC JTC 1/SC 29/WG 11, 2013: JCTVC-M0350.
[11]	Tan T K, Boon C S, Suzuki Y.Intra prediction by template matching[C]//Proceedings of International Conference on Image Processing, ICIP.Piscataway, NJ: IEEE Press, 2006: 1693-1696.
[12]	Tan T K, Boon C S, Suzuki Y.Intra prediction by averaged template matching predictors[C]//Proceedings of 4th Annual IEEE Consumer Communications and Networking Conference, CNCC.Piscataway, NJ: IEEE Press, 2007: 405-409.
[13]	Wige E, Yammine G, Amon P, et al.Sample-based weighted prediction with directional template matching for HEVC lossless coding[C]//Proceedings of 2013 Picture Coding Symposium (PCS).Piscataway, NJ: IEEE Press, 2013: 305-308.
[14]	Lan C, Xu J, Wu F, et al.Intra frame coding with template matching prediction and adaptive transform[C]//Proceedings of International Conference on Image Processing, ICIP.Piscataway, NJ: IEEE Press, 2010: 1221-1224.
[15]	Su H, Han J N, Xu Y W.An optimized template matching approach to intra coding in video/image compression[C]//Proceedings of SPIE-IS Electronic Imaging-Visual Information Processing and Communication V.Bellingham WA: SPIE, 2014: 902904.
